Navigation and Orientation

Global Navigation Satellite Systems (GNSS) have been designed to provide three primary functions: position, navigation and time (PNT). GNSS signals enable users to estimate the position of the satellite at broadcast time and measure the distance from each satellite, to determine the antenna’s position.

The primary design objective of the US Global Positioning System (GPS) was to provide global positioning services for the US Airforce. At the same time, it was realized that there were many civilian applications that would benefit from accurate positioning.

Today it is hard to imagine life without GNSS positioning. GNSS has revolutionized all aspects of positioning and navigation. Modern phone applications, for example, enable users to estimate their position and navigate through unfamiliar cities, while precision agriculture enables the precise application of fertilizer, insecticides and herbicides reducing the chemicals used and protecting the environment.

Tallysman GNSS manufactures antennas that have centimeter to millimeter phase offsets. These precise antennas enable extremely precise positioning and navigation. Tallysman provides a range of patented antennas (patches, helical, crossed dipole) that meet the accuracy and precision needs required by the most demanding applications.

Key features include:

  • Accurate and precise positioning with Tallysman’s patented antenna technology
  • Multi constellation coverage to maximize the number of observations available for position and time estimation (GPS, QZSS, GLONASS, Galileo, and BeiDou)
  • Multi-signal and multi-band support
  • Superior performance in high reflection environments by minimizing multi-path effects
  • Optional pre-filters to enhance out-of-band signal rejection (such as the 700 MHz band)

  • Lightweight and robust antennas ideally sited for use in field RTK and PPP applications
  • IGS and NGS calibrated antennas
  • Embedded versions for use in custom enclosure (custom tuning available)
  • Wide voltage range to work with virtually every receiver on the market
  • Strong electrostatic discharge immunity
  • Rugged housings

Navigation and Orientation Antennas:

Single Band

Housed, Embedded

TW1010TW1012TW1320TW1322TW1322TW1421TW1422TW1430
TW1722TW2010TW2012TW2100TW2106TW2108TW2410TW2412
TW2706TW2708TW2710TW2712TW2743TW2920TW2926TW3010
TW3012TW3040TW3042TW3100TW3142TW3150TW3152TW3320
TW3322TW3379TW3400TW3402TW3440TW3442TW3710TW3712
TW3740TW3742TW3752TW4020TW4022TW4027TW4029TW4421
TW4422TW4721HC771VP6100

Dual Band

Housed, Embedded

TW1721TW1825TW1829TW1889TW2406TW2408TW3867TW3872
TW3872ETW3887TW3892TW7872TW7875TW7876TW7882TW8825
TW8829HC871EHC872HC872EVP6200

Triple Band

Housed, Embedded

TW3929ETW3967TW3972ETW7972HC882
HC882EHC977HC977EVP6300

Iridium

TW2600A

Full GNSS

VP6000VSP6037VSP6037L
