Marine

GNSS has significantly altered and improved Maritime operations.  GNSS is used as a source of positioning, navigation, and timing data, (PNT) for a broad range of maritime applications. Marine applications also often require GNSS correction services to enable Precise Point Positioning (PPP) services, which are often in the L-band which is broadcast just below the GPS L1 band. GNSS data is used for such applications as Automatic Identification Systems (AIS), autonomous vessels, smart buoys, ocean survey and mapping, timing information for the integrated Electronic Chart Display and Information Systems (ECDIS) and Search and Rescue to name but a few.  These systems require GNSS antennas that can not only survive the most challenging environmental conditions – high winds, rough seas, temperature extremes, salt and ice but can also operate in difficult RF environments with port infrastructure and other shipping causing signal reflections.

Modern GNSS receivers are capable of tracking multiple constellations (GPS/QZSS/GLONASS /Galileo/BeiDou). Calian’s multi constellation and multi frequency technology is necessary to provide the precision that many marine applications require. Calian has antennas to satisfy virtually all marine applications requirements.

Key features include:

  • Accurate and precise positioning with Calian’s patented antenna technology
  • Models, which are IP69k (up to 5,000psi) waterproof
  • Multi constellation coverage to maximize the number of observations available for position and time estimation (GPS, QZSS, GLONASS, Galileo, and BeiDou)
  • Multi-signal and multi-band support
  • Iridium-certified antennas providing superior reliability and performance with Accutenna® technology, which provides truly circular response over the entire antenna bandwidth
  • Excellent multi-path rejection for superior performance in high multi-path/reflection environments
  • Optional pre-filters to enhance out-of-band signal rejection
  • Wide voltage range for broad receiver compatibility
  • Embedded versions for use in custom enclosures with custom-tuning available
  • Strong electrostatic discharge immunity
  • Robust housings with mounting options

Marine Antennas:

Single Band

TW3010TW3012TW3040TW3042TW3100TW3142TW3150TW3152
TW3320TW3322TW3379TW3400TW3402TW3440TW3442TW3710
TW3712TW3740TW3742TW3752VP6100

Dual Band

Housed, Embedded

TW3867TW3872TW3872ETW3887TW3892VP6200

Triple Band

Housed, Embedded

TW3929ETW3967TW3972EVP6300

Iridium

Housed, Embedded

TW1600TW3600

Full GNSS

VSP6037LVP6000
